[Unity 3D] MiniRPG : 화면 터치로 이동하기, 애니메이션

화면 터치로 이동하기







using System.Collections;
using System.Collections.Generic;
using UnityEngine;

public class InputTestMain : MonoBehaviour
{
    public Transform point;
    public Hero hero;
    void Update()
    {
        if(Input.GetMouseButtonDown(0))
        {
            Ray ray = Camera.main.ScreenPointToRay(Input.mousePosition);
            RaycastHit hit;
            if (Physics.Raycast(ray, out hit, 1000))
            {
                //Debug.Log(hit.point);
                var tpos = new Vector3(hit.point.x, 0, hit.point.z);
                this.point.position = hit.point;
                this.hero.Move(tpos);
            }
            Debug.DrawRay(ray.origin, ray.direction * 1000f, Color.red, 1f);
        }
    }
}

using System.Collections;
using System.Collections.Generic;
using UnityEngine;

public class Hero : MonoBehaviour
{
    public float moveSpeed;
    private Coroutine moveRoutine;

    public void Start()
    {
        Debug.Log("start");
    }

    //초기화 메서드
    public void Init()
    {
        Debug.Log("Init");
    }
    public void Move(Vector3 tpos)
    {
        Debug.Log(tpos);

        this.transform.LookAt(tpos);

        if(this.moveRoutine != null)
        {
            StopCoroutine(this.moveRoutine);
        }
        this.moveRoutine = StartCoroutine(this.MoveImpl(tpos));

    }
    private IEnumerator MoveImpl(Vector3 tpos)
    {
        //Vector3 dir = (tpos - this.transform.position).normalized;  //단위 벡터

        while(true)
        {
            //this.transform.Translate(dir * this.moveSpeed * Time.deltaTime);
            this.transform.Translate(Vector3.forward * this.moveSpeed * Time.deltaTime);
            //거리를 구하자
            //var dir = tpos - this.transform.position;
            //var distance = dir.magnitude;
            float distance = Vector3.Distance(tpos, this.transform.position);
            Debug.Log(distance);
            if (distance <= 0.1f)
            {
                break;
            }

            yield return null;
        }
    }
}



//카메라에서 스크린 포인트를 통과하는 광선을 반환합니다. Ray ray = Camera.main.ScreenPointToRay(Input.mousePosition); //이동할 방향을 바라본다 this.transform.LookAt(tpos); //앞으로 이동한다 this.transform.Translate(Vector3.forward * this.moveSpeed * Time.deltaTime); //레이케스트의 충돌확인 Physics.Raycast(ray, out hit, 1000) ------------------------------------------------------------------------------------------ Physics.Raycast 활용하여 3D 공간에서 충돌 체크하기 https://mingu.kr/82

---

https://docs.unity3d.com/ScriptReference/Camera.ScreenPointToRay.html

Unity - Scripting API: Camera.ScreenPointToRay



https://docs.unity3d.com/kr/530/ScriptReference/Transform.LookAt.html

Unity - 스크립팅 API: Transform.LookAt

---

애니메이션 넣기



using System.Collections;
using System.Collections.Generic;
using UnityEngine;

public class Hero : MonoBehaviour
{
    public float moveSpeed;
    private Coroutine moveRoutine;
    public GameObject model;
    private Animation anim;

    public void Start()
    {
        Debug.Log("start");
        this.model = GameObject.Find("Model");
        this.anim = this.model.GetComponent<Animation>();
    }

    //초기화 메서드
    public void Init()
    {
        Debug.Log("init");
    }

    public void Move(Vector3 tpos)
    {
        Debug.Log(tpos);

        this.transform.LookAt(tpos);

        if (this.moveRoutine != null)
        {
            StopCoroutine(this.moveRoutine);
        }
        this.moveRoutine = StartCoroutine(this.MoveImpl(tpos));

    }
    private IEnumerator MoveImpl(Vector3 tpos)
    {
        //Vector3 dir = (tpos - this.transform.position).normalized;  //단위 벡터
        this.anim.Play("run@loop");
        while (true)
        {
            //this.transform.Translate(dir * this.moveSpeed * Time.deltaTime);
            this.transform.Translate(Vector3.forward * this.moveSpeed * Time.deltaTime);
            //거리를 구하자
            //var dir = tpos - this.transform.position;
            //var distance = dir.magnitude;
            float distance = Vector3.Distance(tpos, this.transform.position);
            Debug.Log(distance);
            if (distance <= 0.1f)
            {
                break;
            }

            yield return null;
        }
        this.anim.Stop("run@loop");
        this.anim.Play("idle@loop");
    }
}

using System.Collections;
using System.Collections.Generic;
using UnityEngine;

public class InputTestMain : MonoBehaviour
{
    public Transform point;
    public Hero hero;

    void Update()
    {
        if (Input.GetMouseButtonDown(0))
        {
            Ray ray = Camera.main.ScreenPointToRay(Input.mousePosition);
            RaycastHit hit;
            if (Physics.Raycast(ray, out hit, 1000))
            {
                //Debug.Log(hit.point);
                var tpos = new Vector3(hit.point.x, 0, hit.point.z);
                this.point.position = hit.point;
                this.hero.Move(tpos);
            }
            Debug.DrawRay(ray.origin, ray.direction * 1000f, Color.red, 1f);
        }
    }
}

//애니메이션을 실행한다 this.animation.Play("run@loop"); //애니메이션을 멈춘다 this.animation.Stop("run@loop");



---

https://docs.unity3d.com/ScriptReference/Animation.Play.html

Unity - Scripting API: Animation.Play

https://docs.unity3d.com/kr/530/ScriptReference/Animation.Stop.html

Unity - 스크립팅 API: Animation.Stop

---
